Working Voltage Range

DC:  6V-24V

Rating Power

6V:  0-42W/12V:  0-42W/24V:  0-64W

Static Water Head

0-14 M

Static Flow Rate

0-15 L/min

Lifespan

Continuous operation≤24hrs, under normal working surrounding >20000hrs

Working Environment

Liquid: From weak acid to weak base, work on land (Non submergible)

Max Noise

Under normal working status, 1M distance over test instrument <45dB

Max Working Temperature

Under normal surroundings, fluid medium temperature ≤90℃ (Aluminum alloy Shell)

Application

High building water supply, Garden sprinklers, irrigation, etc.

Size

IP Grade

Inlet

Outlet

Remarks

Length

(mm）

Width（mm）

Height（mm）

OD

（mm）

ID（mm）

OD

（mm）

ID

（mm）

Inlet and outlet with non-slip insert

76

57

107

IP67

φ15

φ10

φ10

φ7
