Working Voltage Range

DC:  6V-24V

Rating Power

6V:  0-35W  / 12V:  0-35W / 24V: 0-70 W

Static Water Head

0-15 M

Static Flow Rate

0-19L/min

Lifespan

Continuous operation≤24hrs, under normal working surrounding >20000hrs

Working Environment

Liquid: From weak acid to weak base, work in water  (submergible)

Max Noise

Under normal working status, 1M distance over test instrument <50dB

Max Working Temperature

Under normal surroundings, fluid medium temperature ≤70℃

Application

High building water supply, Garden sprinklers, Irrigation, etc.

Size

IP Grade

Inlet

Outlet

Remarks

Length

(mm）

Width（mm）

Height（mm）

OD

（mm）

ID

（mm）

OD

（mm）

ID

（mm）

Inlet and Outlet with standard thread

155

57

144

IP68

1inch Standard thread pipe

φ18.6

1inch Standard thread pipe

φ18.6
